• Platinum-painted front bumper
• Platinum-painted rear step bumper w/safety chain holes
• Front stone guards/rear mud flaps
• Platinum-painted grille bars
• Body-color grille surround
• (4) black cargo box tie-down hooks
• Sail mount black manual foldaway mirrors
• Solar tinted glass
• Intermittent windshield wipers
• (2) cab doors
• Quick-release tailgate

• Cloth front 60/40 split bench seat
• Black vinyl floor covering
• Floor consolette w/dual cupholders, removable black ash cup
• Black steering wheel
• Tachometer
• Black-faced instrument cluster
• Securilock passive anti-theft system
• Electronic AM/FM stereo radio w/digital clock, (2) speakers
• Instrument panel 12-volt pwr point
• Warning chimes-inc: headlights-on, key-in-ignition, safety belt
• Color-keyed glove box
• Cigarette lighter
• Manual day/night interior rearview mirror
• Color-keyed door trim panels w/padded armrest & black door handles
• Soft contrasting color-keyed headliner
• Color-keyed cloth sun visors w/LH/RH strap
• Driver/passenger-side A-pillar-mounted grab handles
• Rear-of-cab coat hook
• Front dome light

• 4-wheel anti-lock brake system
• Driver & front passenger airbags w/manual passenger-side deactivation switch
• Adjustable height front shoulder safety belts w/top release
• Child safety seat restraint latches (LATCH)
• Dual-note horn

3.0L (182) SEFI V6 ENGINE

• (STD)

• AM/FM radio
• Power steering
• ABS brakes
• Dual front impact airbags
• Front anti-roll bar
• Front wheel independent suspension
• Passenger cancellable airbag
• Rear step bumper
• Tachometer
• Voltmeter
• Cloth 60/40 Split Bench Seat
• Front Center Armrest w/Storage
• Variably intermittent wipers

• Mileage
• EPA Fuel Economy Est - City (MPG): 19
• EPA Fuel Economy Est - Hwy (MPG): 23
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 540
• Maximum Alternator Capacity (amps): 95
• Cooling System
• Total Cooling System Capacity (qts): 7.2
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2400
• Gross Axle Wt Rating - Rear (lbs): 2600
• Curb Weight - Front (lbs): 1802
• Curb Weight - Rear (lbs): 1364
• Gross Vehicle Weight Rating Cap (lbs): 4600
• Gross Combined Wt Rating (lbs): 6000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2480
• Dead Weight Hitch - Max Tongue Wt. (lbs): 248
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2400
• Spring Capacity - Rear (lbs): 2600
• Axle Type - Front: Independent SLA
• Axle Type - Rear: Ford Semi-Floating
• Axle Capacity - Front (lbs): 2625
• Axle Capacity - Rear (lbs): 2750
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 30
• Shock Absorber Diameter - Rear (mm): 30
• Stabilizer Bar Diameter - Front (in): 1.06
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.28 x 1.02
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 10.00 x 2.50
• Tires
• Front Tire Order Code: T7H
• Rear Tire Order Code: T7H
• Front Tire Size: P225/70R15
• Rear Tire Size: P225/70R15
• Spare Tire Size: Compact
• Front Tire Capacity (lbs): 1594
• Rear Tire Capacity (lbs): 1594
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: 765
• Revolutions/Mile @ 45 mph - Rear: 765
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 15 x 6.0
• Rear Wheel Size (in): 15 x 6.0
• Spare Wheel Size (in): - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), On Center: 19.2
• Turning Diameter - Curb to Curb (ft): 42.7
• Turning Diameter - Wall to Wall (ft): 44.6
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 19.5
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 125.7
• Length, Overall w/o rear bumper (in): 202.9
• Width, Max w/o mirrors (in): 69.4
• Height, Overall (in): 64.8
• Overhang, Front (in): 33.3
• Overhang, Rear w/o bumper (in): 43.9
• Front Bumper to Back of Cab (in): 121.3
• Cab to Axle (in): 37.7
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 27.9
• Frame Width, Rear (in): 32.8
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): 6.7
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 71.8
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 52.0
• Cargo Box Width @ Wheelhousings (in): 40.4
• Cargo Box (Area) Height (in): 16.5
• Tailgate Width (in): 52.0
• Ext'd Cab Cargo Volume (ft³): 37.3
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 39.2
• Front Leg Room (in): 42.2
• Front Shoulder Room (in): 53.8
• Front Hip Room (in): 52.7
• Second Head Room (in): 35.6
• Second Leg Room (in): 40.3
• Second Shoulder Room (in): 15.3
• Second Hip Room (in): 19.8
• Summary
• Vehicle Name: Ford Ranger
• Body Style: Supercab 6' Styleside
• Body Code: 125.7" WB
